Hyperbolic arm telescopic awning, strong arms support awning

Brand Name : DM AWNING

Model Number : DMFS09

MOQ : 1 set

Payment Terms : L/C, T/T, Western Union

Supply Ability : 500 sets per day

Delivery Time : 3-7 workdays

Packaging Details : 1 set per carton

Certification : CE

Place of Origin : China

Roller : Ø 70 mm, Ø 80 mm Steel or Aluminum

Front bar : Aluminum 95*68 mm

Square bar : 40*40 mm

Arm : 55*27/60*30 mm

Gear box : 1:11

Adjusted-angle : 5°to 75°

Fram : Outdoor Power Coated

Connector : Aluminum Die. Cast

Fabric : Polyester or Acrylic

Max size : width 6.0M, Projectione 5.0M

Arms available : 1.5M, 2.0M, 2.5M, 3.0M, 3.5M, 4.0M, 4.5M, 5.0M
